1/2HP MARATHON 1750RPM 56C TENV 90VDC WASHDOWN MOTOR Z634

1/2HP MARATHON 1750RPM 56C TENV 90VDC WASHDOWN MOTOR Z634


Part Number:

Z634

Model/Spec Number:

056E17V2003

Manufacturer:

Marathon Obsolete
Z634 MARATHON 1/2HP NEMA High voltage permanent magnet DC Washdown motor designed for extended life in applications requiring regular washdown as in food processing, or otherwise wet, high humidity environments. WASHGAURD motors retard the entrance of water during cleaning operations and release any water that does enter the motor. Extra protection for the motor's interior prevents rust and corrosion build-up and drains release trapped moisture to insure a longer life than possible with a standard motor.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

39 lbs

Dimensions:

10 x 20 x 10 inches

HS Code:

8501.31.0000

UPC:

722856025982

Technical Details

Application:

Epoxy Washdown

Output HP:

1/2

Output KW:

0.37

Output RPM:

1750

Frame NEMA:

56C

Mount NEMA:

C-Face With Base

Input Voltage DC:

90

Full Load Amps:

5.0

Winding:

Permanent Magnet

Enclosure NEMA:

TENV

Product Information Packet
