1HP LEESON 1725RPM 56CZ TEFC 3PH WATTSAVER BRAKE MOTOR 1110274.00
1HP LEESON 1725RPM 56CZ TEFC 3PH WATTSAVER BRAKE MOTOR 1110274.00
Product Overview
1110274.00 LEESON 1HP 56CZ Three Phase Totally Enclosed Brake motor is designed for use with conveyors, packaging equipment, machine tools, hoists, elevators and door operators.Part Number:
1110274.00Model/Spec Number:
1110274.00Manufacturer:
Regal MOQManufacturer Part Number:
C6T17FC419ATechnical Details
Specifications
| Brand | Leeson |
| Application | Brakemotor |
| Output HP | 1 |
| Output KW | 0.75 |
| Output RPM | 1765 |
| Frame Size NEMA | 56CZ |
Documentation
Additional Information
LEESON Fail-safe positive, stop and hold brake-motors. Brakes are spring set. Load stopped automatically when power is turned off. LEESON brake-motors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The standard brake is manufactured by Stearns. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor.
Features Include:
- 5/8" Keyed output shaft
- 7/8" Keyed stub shaft (reference drawing)
- High-quality ball bearings
- Easy-to-read nameplate
- UL Recognized Component Listing and CSA approval.
