1HP MARATHON 1750RPM 143TCZ TENV 3PH MOTOR Y535A

Product Overview

Y535A MARATHON 1HP Three Phase Black Max Inverter (Vector) Duty motor is designed for use with material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

Part Number:

Y535A

Model/Spec Number:

143THTBD5374

Manufacturer:

Regal Rexnord Commercial

Manufacturer Part Number:

Y535A

Technical Details

Specifications

Brand	Marathon
Application	Vector Duty
Output HP	1
Output KW	0.75
Output RPM	1750
Frame Size NEMA	143TCZ

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Designed for inverter or vector applications where up to a 1000:1 Constant Torque speed range is required. Typical uses include: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

FEATURES:

MAX GUARD® Class F insulation system
MAX GUARD® inverter rated insulation system exceeds NEMA MG1 Part 31
Constant Torque operation from 0 to base speed on Vector Drive
Constant Horsepower operation up to twice base RPM
40ºC ambient 1.0SF inverter power
Optimized for operation with IGBT inverter (NEMA Design A)
Normally closed thermostats (one per phase, Class F)
Bolt-on removable base for footless mounting option
Ball Bearings
Encoder and brake provisions included on opposite drive end (maximum 10 lb-ft brake)
UL Recognized, CSA Certified, and CE Mark
Three year warranty
