GROVE TXMQ-2.000-140TC-140TC RATIO MULTIPLIER 708204L
GROVE TXMQ-2.000-140TC-140TC RATIO MULTIPLIER 708204L
Product Overview
708204L GROVE TXMQ-2.000-140TC-140TC Die Cast Aluminum Ratio Multiplier can reduce or increase input speed when combined with right angle units for high ratios.Part Number:
708204LModel/Spec Number:
GR-TXMQ-2.000-140TC-140TCManufacturer:
Grove GearManufacturer Part Number:
708204LTechnical Details
Specifications
| Design | Ratio Multiplier |
| Output RPM@1750 | 875 |
| Output Torque (lb-in) | 424 |
| Max Input HP @1750 | 5.0 |
| Ratio | 2.000 |
| NEMA Input Config | 143-5TC / 0.875" |
Additional Information
GROVE Die Cast Aluminum Ratio Multipliers can reduce or increase input speed when combined with right angle units for high ratios.
FEATURES:
- Helical gearing to optimize system efficiency.
- Viton® double lip seals provide extended life through increased resistance to high temperature, abrasion and chemicals.
- Washdown Friendly Exterior
- Die Cast Aluminum construction
- Factory-filled with premium Mobil Glygoyle 460 polyalkalene glycol lubricant – USDA Class H1 approved.
- Standard Grove Gear blue paint
- Internal compression chamber eliminates breather vent
- Universal mounting positions
- High Torque Ratings
