GR-HMQ815-10-H1-56-10 GROVE 10:1 H1 RIGHT ANGLE GEAR REDUCER GR8150563.10
GR-HMQ815-10-H1-56-10 GROVE 10:1 H1 RIGHT ANGLE GEAR REDUCER GR8150563.10
Part Number:
GR8150563.10Model/Spec Number:
GR-HMQ815-10-H1-56-10Manufacturer:
Grove GearGROVE Gearing products are Non-Returnable. Once the order is placed it cannot be canceled. Standard lead times are 5-10 business days. For urgent expedited orders please contact our office for availability.
MSRP: $1,922.26
Regular Price
USD
$
1,001
89
Shipping Details
Free No Rush Shipping
Weight:
23 lbsDimensions:
12 x 12 x 12 inchesHS Code:
8483.00.0000UPC:
690310005965Technical Details
Specifications
Max Input HP @1750: | 1 |
Output RPM @1750: | 175 |
Reduction Ratio: | 10:1 |
Torque (lb-in)@1750rpm: | 402 |
Overhung Load (lbs.): | 860 |
Shaft Center Distance: | 1.54 |
Shaft Center Height: | 1.91 |
Mount Footprint: | 2.75” x 4.19” |
NEMA Input Mounting: | 56C |
Mount Style: | HMQ |
Documentation
Additional Information
Grove Cast Iron Right Angle Worm Gear Reducer is designed for a wide variety of applications requiring slow speed and high torque, ideal for conveyors, material handling, textile machines, packaging machinery, etc.
FEATURES:
- Heavy duty cast iron housing
- Factory-filled premium Mobil Glygoyle 460 polyalkalene lubricant
- Precision machined mounting surfaces
- O-rings on input and output covers
- Viton double lip seals provide extended life
- NEMA C input flange, Push-off holes
- Bronze worm gear chill cast from high quality bronze
- Tapered roller bearings
- Premium Grade 5 assembly bolts throughout
- Mounting dimensions are interchangeable with most industry standard reducers
