122478.00 LEESON 2HP 230VAC MOTOR C6T17FK142A

Electric Motors

...Machine Tool Motors & Drives

2HP LEESON 1725RPM 143TC TEFC 3PH 230VAC MOTOR 122478.00

Part Number:

122478.00

Manufacturer:

Leeson Obsolete

Manufacturer Part Number:

C6T17FK142A

122478.00 LEESON 2HP Three Phase Inverter Use Only Electric Motor is designed for use where exposure is limited to splashes of water, dust and/or where mild corrosives exist.

Ordering Notes

Motor is designed to operate with VFD (variable frequency drive) Only.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

46 lbs

Dimensions:

13 x 22 x 13 inches

HS Code:

8501.52.4000

Technical Details

Specifications

Brand:	Leeson
Application:	Inverter Only
Output HP:	2
Output KW:	1.5
Output RPM:	1725
Frame Size NEMA:	143TC
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP43
Voltage:	230

Documentation

122478.00 Product Packet.pdf

Additional Information

Machine Tool Motors designed for grinders, milling machines and general purpose tool applications.

Inverter Use Only
7/8" Keyed output shaft
Single Voltage 3-Wire 230VAC
Rigid base with C-Face mounting
1.0 Service factor
Durable rolled steel frame
High-quality ball bearings
UL Recognized Component Listing and CSA approval.
Motor will not operate with conventional motor starter/contactor application.
Motor will operate with the older GEN-2 KBAC drives.
Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.

TEFC Models: For use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. Not for outdoor use without proper shielding or for use with harsh chemicals.
