1HP LEESON 1725RPM 56C TEFC 230VAC 3PH MOTOR 145917.00
1HP LEESON 1725RPM 56C TEFC 230VAC 3PH MOTOR 145917.00
Product Overview
LEESON 145917.00, 1HP Three Phase Electric Motor is designed for use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applicationsPart Number:
145917Model/Spec Number:
NoneManufacturer:
Leeson ObsoleteManufacturer Part Number:
145917.00Technical Details
Documentation
Additional Information
| Catalog Number: | PR145917.00 |
| Description: | 1HP,1725RPM,56C,TEFC,3PH,230VAC,60HZ |
| Ship Weight: | 26 lbs. |
LEESON TEFC Models: For use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. Not for outdoor use without proper shielding or for use with harsh chemicals.
Features Include:
- Durable rolled steel frame
- High-quality ball bearings
- Easy-to-read nameplate
- UL Recognized Component Listing and CSA approval.
- Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 3.6-3.8 | F.L. Amps | 1.9 | F.L. Amps | |
| S. F Amps | 4.2 | S. F Amps | 2.1 | S. F Amps | |
| RPM | 1800 | Hertz | 60 | ||
| HP | 1 | Duty | CONTINUOUS | TYPE | TF |
| KW | .75 | Model Number | C6T17FC2 G | ||
| Frame | 56 C | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | M |
| Insul Class | B | Protection | NOT | Therm.Prot. | |
| Eff 100% | 77 | Eff 75% | PF | 64 | |
| UL | Y-(LEESON UL REC) | CSA | Yes | Bearing OPE | 6203 |
| CC Number | EXEMPT | CE | No | Bearing PE | 6203 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 26 LB | Enclosure | TEFC | Lubrication | POLYREX EM |
| Nameplate | 993500 | Mounting | C FACE | Rotation | REV |
