GROVE GR-WHMQ815-7.5-H-140 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8153514.00

GROVE 800 SERIES WHMQ Cast-Iron Washguard Gear Reducers are designed and built to withstand the rigors of high pressure washdown environments in food service and other wet or humid conditions. A white, food-grade epoxy finish provides superior durability in wet environments and resists caustic cleaning solutions.

FEATURES:

• Vent free design - The Enviro-Seal operates in any mounting position and is standard in all stock WASHGUARD reducers to create a "Sealed For Life" design. There's no need to install a vent.
• Food-Grade Synthetic Oil Mobil Glygoyle PAG 460 meets USDA Class H1 standards while providing superior mechanical/thermal performance and extended life.
• O-ring seals on input and output covers eliminate gaskets, sealants and leaks.
• Viton® double-lip seals and Viton® double-lip seals are up to five times more durable than nitrile seals and provide superior resistance to chemical corrosion in severe applications.
• 303 stainless steel output shaft is corrosion resistant for long life and ease of servicing.
• Stainless steel assembly hardware resists corrosion from moisture and chemicals.
• O-ring on input flange provides a positive seal against moisture intrusion.

NOTE: Torque arm bracket is not supplied with reducer as standard.

Ratio:1	7.5
Input RPM	1750
Output RPM	233.3
Input HP	1.522
Output HP	1.368
Output Torque (lb.-in.)	370
Housing Construction	Cast Iron
Overhung Load (lbs.)	860
Reducer Type	Worm - Right Angle
Center Distance (in)	1.54
Reducer Style	WHMQ
Input Style	C-faced Quill
Frame Size	56C
Assembly	HMQ-L
Output Shaft Assembly	H (Hollow Shaft)
Bore Size (in)	0.625
