6FT-LB MARATHON 56000 SERIES NEMA2 575VAC BLACK BRAKE A315
6FT-LB MARATHON 56000 SERIES NEMA2 575VAC BLACK BRAKE A315
Product Overview
A315 MARATHON 56000 Series Brake Kit fits on both Black Max and Blue Max TENV motors. This can also be used together with the Double C-Face SL56 encoder to make a closed loop inverter brake motor.Part Number:
A315Model/Spec Number:
105602100039Manufacturer:
Regal Beloit PartsManufacturer Part Number:
BM6BRK575Technical Details
Specifications
| Stearns Series | 56000 |
| Static Torque Lb.-ft. | 6 |
| Coil Size | #4 |
| Enclosure NEMA | NEMA2 |
| Enclosure IEC | IP23 |
| Hub Bore Dia. | B: 5/8" |
Additional Information
These Stearns brake kits fit on both Black Max® and Blue Max® TENV motors. This can also be used together with the Double C-Face SL56 encoder to make a closed loop inverter brake motor. For normal (140%) torque rating, do not apply on motors larger than 2 HP. Reduced braking torque and/or longer stopping times can result from applying an undersized brake on higher HP motors.
Related Items
Replacement Parts
MSRP: $1,413.00
