K2018A MARATHON 1.5HP 3-PHASE XRI GENERAL PURPOSE MOTOR 143TTDR16021

1.5HP MARATHON 3490RPM 143TC DP 3PH MOTOR K2018A

Part Number:

K2018A

Model/Spec Number:

143TTDR16021

Manufacturer:

Regal Rexnord Commercial

K2018A MARATHON 1.5HP Three Phase XRI(r) General Purpose Motor for use on gear reducers, pumps, machine tools, and other direct coupled equipment installed in environments that are relatively clean and dry.

Ordering Notes

Discontinued item with limited availability, subject to prior sale. Non-Returnable.

MSRP: $1,109.00

Regular Price

USD

300

QTY

Shipping Details

Weight:

47 lbs

Dimensions:

13 x 20 x 11 inches

HS Code:

8501.52.4000

UPC:

722856051790

Technical Details

Specifications

Brand:	Marathon
Application:	General Purpose
Output HP:	1.5
Output KW:	1.1
Output RPM:	3490
Frame Size NEMA:	143TC
Mount NEMA:	C Face No Base
Enclosure NEMA:	DP
Enclosure IEC:	IP22
Voltage:	230/460

Documentation

Product Information Packet

Additional Information

APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.

FEATURES:

UL recognized component listing and CSA certification
Permanently lubricated sealed bearings

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
