3HP MARATHON 3490RPM 145TC TEFC 3PH EPOXY WASHDOWN MOTOR N613A

APPLICATIONS: Designed for superior extended service in severe environments. Typical applications include food processing areas requiring frequent sanitation procedures using high pressure cleaning with concentrated caustic solutions, areas of high humidity and in chemical environments.

FEATURES:

• MAX GUARD® Class F insulation system
• 1.15 Service Factor on sinewave, 1.0 Service Factor on IGBT power
• Double sealed ball bearings
• Stainless steel conduit box cover, nameplate, fan guard (TEFC only) and hardware
• Cast oversized conduit box with high temperature nitrile gaskets and
  threaded entrance
• Plugged drain holes in each endshield for all angle mounting
• Internal corrosion resistant coatings on frame, base, endshields, rotor and stator
• USDA-approved, white epoxy RUST-OLEUM® paint
• UL Recognized, CSA Certified and CE Mark
• Efficiency levels meet EISA requirements
• Footnotes: V

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
