1/2HP LEESON 1800RPM 71 B34 IP55 3PH IEC MOTOR R367

1/2HP LEESON 1800RPM 71 B34 IP55 3PH IEC MOTOR R367

71 B3 B14.jpg
Picture is for reference only.

Part Number:

R367

Model/Spec Number:

071T17FH5408

Manufacturer:

Regal IEC
R367 LEESON 1/2HP B14 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Ordering Notes

Non returnable. Use product information provided to confirm product specs.

MSRP: $961.00

Regular Price

USD

$

380

00

QTY
Login to View Discounts

Weight:

20 lbs

Dimensions:

10 x 14 x 12 inches

HS Code:

8501.51.4040

UPC:

722856027092

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

1/2

Output KW:

0.37

Output RPM:

1800//1380

Frame Size IEC:

71

Mount IEC:

B3/B14 Foot/C-Face

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

14mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The Globetrotter is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Meets IE3 European and NEMA Premium® efficiencies
  • Class F Insulation, Class B rise @ rated KW
  • Rotatable/Removable Base (63-90 frame)
  • Top Mounted/Oversized gasketed terminal box
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty (Below Deck)
  • 1.15 Service Factor on 60 Hz sine wave, 1.0 SF or VFD
  • IEC Design “N” with NEMA “B” Torques
  • Terminal Blocks, Stud Type, Zero Creepage
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE Marked
