Y538 MARATHON 1.5HP 3-PHASE INVERTER (VECTOR) DUTY MOTOR 145THTR5326

1.5HP MARATHON 1755RPM 145TC TENV 3PH MOTOR Y538

Part Number:

Y538

Model/Spec Number:

145THTR5326

Manufacturer:

Regal Rexnord Commercial

Y538 MARATHON 1.5HP Three Phase Black Max Inverter (Vector) Duty motor is designed for use with material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

MSRP: $2,073.00

Regular Price

USD

774

QTY

Shipping Details

Weight:

52 lbs

Dimensions:

13 x 20 x 11 inches

HS Code:

8501.52.8040

UPC:

722856024756

Technical Details

Specifications

Brand:	Marathon
Application:	Vector Duty
Output HP:	1.5
Output KW:	1.1
Output RPM:	1755
Frame Size NEMA:	145TC
Mount NEMA:	C Face With Base
Enclosure NEMA:	TENV
Enclosure IEC:	IP43
Voltage:	230/460

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Designed for inverter or vector applications where up to a 1000:1 Constant Torque speed range is required. Typical uses include: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

FEATURES:

MAX GUARD® Class F insulation system
Constant Torque operation from 0 to base speed on Vector Drive
Constant Horsepower operation up to twice base RPM
Continuous duty at 40ºC ambient
Optimized for operation with IGBT inverter (NEMA Design A)
Normally closed thermostats (one per phase, Class F)
Bolt-on removable base for footless mounting option
Ball Bearings
Encoder and brake provisions included on opposite drive end (maximum 10 lb-ft brake)
UL Recognized, CSA Certified, and CE Mark
Three year warranty
