7.5HP MARATHON 1765RPM 213TC 575V TENV 3PH MOTOR Y560

Product Overview

Y560 MARATHON 7.5HP Three Phase Black Max Inverter (Vector) Duty motor is designed for use with material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

Part Number:

Y560

Model/Spec Number:

213THTL7736

Manufacturer:

Marathon LLC

Manufacturer Part Number:

Y560

Technical Details

Specifications

Brand	Marathon
Application	Vector Duty
Output HP	7.5
Output KW	5.5
Output RPM	1765
Frame Size NEMA	213TC

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Designed for inverter or vector applications where up to a 1000:1 Constant Torque speed range is required. Typical uses include: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

FEATURES:

MAX GUARD® Class F insulation system
Constant Torque operation from 0 to base speed on Vector Drive
Constant Horsepower operation up to twice base RPM
Continuous duty at 40ºC ambient
Optimized for operation with IGBT inverter (NEMA Design A)
Normally closed thermostats (one per phase, Class F)
Ball Bearings
Encoder and brake provisions included on opposite drive end (maximum 10 lb-ft brake)
UL Recognized, CSA Certified, and CE Mark
Three year warranty
