477203515U03 STEARNS 2VR SERIES 230V 35A SOLID STATE SINPAC SWITCH
477203515U03 STEARNS 2VR SERIES 230V 35A SOLID STATE SINPAC SWITCH
Picture is for reference only.
Part Number:
477203515U03Model/Spec Number:
2VR-35-310Manufacturer:
Stearns/SINPACManufacturer Part Number:
4-7-72035-15-U03Discontinued item, Non-Returnable.
Click below to view suggested functional replacement.
Shipping Details
Weight:
2 lbsDimensions:
5 x 5 x 3 inchesHS Code:
8536507000UPC:
662864048941Technical Details
Specifications
Cut Out Voltage: | 310 VCO |
Max Amperage Rating: | 35 Amps |
Package Style: | Cap Case 1.822 dia. x 3.372 long |
Series: | Capacitor Start/Capacitor Run Only |
Start Winding Voltage: | 230VAC |
Documentation
Additional Information
- 2VR Series
- Capacitor Start/Capacitor Run Motors Only
- 230V 50/60Hz Start Circuit Voltage
- Standard 35 Amps
- Capacitor Case 1.822 dia. x 3.372 long
- UL Recognized
- 310 VCO
- 5 Second Duty
Discontinued item, Non-Returnable.
Click below to view suggested functional replacement.
Shipping Details
Weight:
2 lbsDimensions:
5 x 5 x 3 inchesHS Code:
8536507000UPC:
662864048941
