125FT-LB STEARNS 81/82000 Series Hi-Torque AC Support Plate Assembly 54220713609

125FT-LB STEARNS 81/82000 Series Hi-Torque AC Support Plate Assembly 54220713609

Picture is for reference only.

Part Number:

54220713609

Model/Spec Number:

5-42-2071-36-09

Manufacturer:

Stearns Parts
5-42-2071-36-09 STEARNS 125FT-LB 81000/82000 Series Hi-Torque AC Support Plate Assembly

Ordering Notes

This Stearns Product is Non-Returnable. STEARNS Products are normally stocked, but 10-15 day lead times may apply. Please do not order expedited shipping without contacting our sales office for stock and availability.

Informational Item

This is item is for informational purposes only and cannot be purchased. Please contact customer service for more details.

Weight:

38 lbs

Dimensions:

16 x 16 x 10 inches

HS Code:

8505.90.7501

UPC:

662327974619

Technical Details

Stearns Series:

81000, 82000

Static Torque Lb.-ft.:

125

Coil Size:

#9

Enclosure NEMA:

NEMA2, NEMA4

Enclosure IEC:

IP23, IP54

Release:

Pull Release

Endplate Material:

Cast Iron

Mount Orientation:

Horizontal

Application:

High Torque

81000 Product Packet

Proper Installation of STEARNS support plate assembly: Reset Lever Arm on Support Plate
Image for #9 STEARNS 81000/82000 Series AC Solenoid Assembly 512552900

#9 STEARNS 81000/82000 Series AC Solenoid Assembly 512552900

MSRP: $1,280.78

Regular Price

$

730

56

Image for #9 STEARNS Injection Molded 115VAC Class-H Coil 596692950
