051-203-7005 BISON 1/14HP 180VDC FHP Motor 0512037005

1/14HP BISON 2350RPM 32 Frame 180VDC Permanent Magnet Motor 051-203-7005

Part Number:

0512037005

Manufacturer:

Bison Gear

Manufacturer Part Number:

051-203-7005

051-203-7005 BISON 1/14HP 180VDC FHP Motor is a precision sub-fractional horsepower DC permanent magnet motor designed for use with full wave non-filtered SCR controls for adjustable speed applications requiring dynamic braking and constant torque throughout the speed range.

Ordering Notes

Minimum quantity purchase. Subject to production lead times.

This part is non-returnable. Use the Cut-Sheet provided to confirm product specs.

MSRP: $425.15

Regular Price

USD

340

QTY

Shipping Details

Free No Rush Shipping

Weight:

9 lbs

Dimensions:

16 x 6 x 6 inches

HS Code:

8501.31.4000

Technical Details

Specifications

Application:	General Purpose
Output HP:	1/14
Output KW:	0.05
Output RPM:	2350
Frame NEMA:	32
Mount NEMA:	C-Face No Base
Input Voltage DC:	180
Full Load Amps:	0.45
Winding:	Permanent Magnet
Enclosure NEMA:	TENV

Documentation

Product Information Packet

Additional Information

BISON Permanent Magnet 32 Frame FHP DC Motors are manufactured with the highest quality. The motor assemblies are Dynamically balanced, diamond turned, Class H polyester trickle varnishing, premium grade ceramic magnets with a premium finish gloss black powder coat. Ready to serve the most robust commercial and industrial applications. Rated for continuous duty with full wave unfiltered rectified SCR (thyristor) controls. Linear speed torque characteristics throughout the speed range. High starting torques. Reversible rotation from a simple two lead connection.
