3/4HP MARATHON 1690RPM 80 TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R310

3/4HP MARATHON 1690RPM 80 TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R310


Part Number:

R310

Model/Spec Number:

080T17FH5326

Manufacturer:

Regal IEC
R310 MARATHON 3/4HP Globetrotter B3 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

27 lbs

Dimensions:

12 x 16 x 13 inches

HS Code:

8501.51.4040

UPC:

722856026248

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

3/4

Output KW:

0.56

Output RPM:

1690//1390

Frame Size IEC:

80

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

19mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The Globetrotter is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • B3 Rigid Base mounting
  • Meets IE3 European and NEMA Premium® efficiencies
  • Nameplated 60/50 hertz rated at same HP
  • MAX GUARD® Class F Insulation, Class B rise @ rated KW
  • Rotatable/Removable Base
  • 10:1 Variable Torque, Constant Torque speed range as noted
  • Top Mounted/Oversized gasketed terminal box
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty (Below Deck)
  • 1.15 Service Factor on 60 Hz sine wave, 1.0 SF or VFD
  • IEC Design “N” with NEMA “B” Torques
  • Terminal Blocks, Stud Type, Zero Creepage
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE Marked
