1/6HP MARATHON 1075RPM 48Y 208-230V TEAO 1PH MOTOR X411

APPLICATIONS: Direct drive condenser fan is for all angle mounting. This motor needs to be mounted within the airflow of the fan for proper cooling.

PERMANENT SPLIT CAPACITOR: Operates similarly to capacitor-start motors, but there is no centrifugal starting switch and what correspond to the "start" windings (second windings) are permanently connected to the power source (through a run capacitor), along with the run windings. PSC motors are frequently used in air handlers, blowers, and fans (including ceiling fans) and other cases where variable speeds are desired.

FEATURES:

• Capacitor not included
• X411 replaces Lennox No. 47F9901, Magnetek No. 9402, & Marathon Nos. 48A11T300 & 48A11T247
• Automatic reset thermal protector (under locked rotor only)
• Frame and end brackets enclosed
• Single-Speed models
• All Angle mounting
• Lug mount kits and other accessories available
• Ball bearings
• Weather resistant reversing plug
• 30” long leads
• Shaft slinger
• 1-1/2” Thru-bolts on shaft end, 1” thrubolts on lead end
• Weep holes with removable plugs on end brackets. Remove bottom plug after installation.
• 40°C ambient
• UL Recognized and CSA Certified
